Series KM- 03

Hydrocarbon machines

Realstar KM 03 Series Machines are offered in five models:
KM 343 – 18 Kg. Capacity
KM 403 – 20 Kg. Capacity
KM 503 – 25 Kg. Capacity
KM 703 – 32 Kg. Capacity
KM 803 – 40 Kg. Capacity

Faster drying for Shorter cycle times
It’s quite simple: shorten the drying time, shorten the cycle time, increase production and increase profits.
Realstar engineers have developed a new drying system that will shorten drying times without a loss of efficiency through: Doubling the air flow through cylinder.
Relocating the fan midway in the coils and coordinating the refrigeration and heating coils during the drying phase to circulate larger air volume into the cylinder.
A new Automatic Electronic Dry Control system for maximum efficiency.
For ease of maintenance, our new refrigeration system is now divided into three segments: The compressor, the refrigeration coil, and the heat exchange coil.
All three of these components can be individually and simply serviced, without removal of the entire system due to AEROQUIP unions. Simplified maintenance and less downtime!

Series KM- 03

Model

KM 343

KM 403

KM 503

KM 703

KM 803

Load capacity ratio 1:20 lt

18

20

25

32

40

Volume of the drum lt

340

400

500

645

800

Diameter  mm

900

1000

1000

1200

1200

Depth mm

535

510

640

570

710

Wash speed rpm

12 - 50

12 - 50

12 - 50

12 - 50

12 - 50

Extract speed rpm

300 - 540

300 - 540

300 - 540

300 - 450

300 - 450

Door opening mm

500

500

500

500

500

Useful volume 1st tank lt

110

160

160

240

240

Useful volume 2nd tank lt

110

160

160

240

240

Useful volume 3rd tank lt

200

200

200

330

330

Useful still capacity lt

190

260

260

360

360

Total volume lt

230

325

325

455

455

Fractional Distillation
One of the most important phases in the proper operation of an alternative solvent machine is that of distillation.
An improperly designed distillation system will lead to odor causing bacteria in the solvent tanks which will transfer onto the customer’s clothes. To prevent this from occurring, Realstar engineers have de-signed a system referred to as fractional distillation which is found in all of our KT and KM Series machines. Unlike the atmospheric stills used in perc machines, alternative solvent machines distill under vacuum to achieve the higher boiling points of these solvents. Our fractional distillation system regulates the proper amounts of solvent to the still and tanks to prevent harmful bacteria causing foam and resulting odors
